Edition 02 to 12/2013
9.11
SERVICE MANUAL
9.4 ADJUSTING KNOB
After found the final settings for hot milk foam
it’s possbile to fix the plastic knob available in
the box.
The knob has a pin to reduce the setting range
available for the end customer ½ turn,
1 Put the pin in the centre of the slot.
2 Fix the knob tightening the 2mm allen screw
in the bottom part inside the door.
Fig. 33
Fig. 32
