Nuova Simonelli TALENTO - Description

Edition 02 to 12/2013
1.2
SERVICE MANUAL
KEY:
1 Coffee bean holder cap
2 Control panel
3 Front door
4 Steam pipe / Hot water pipe
5 Drop collecting tray grid
6 Coffee grounds drawer
7 Coffee nozzles
8 Milk/Cappuccino nozzle
9 Control panel hatch opening / locking key
10 Ground coffee conveyor hat ch
11 Milk suction tube
12 Milk flow adjusting tap
13 Water collecting tray
1.1 DESCRIPTION
Fig. 2
1
11
12
6
8
5
13
7
10
9
2
3
4
