Nvidia BlueField-3 User Manual

53
•
•
8 Specifications
8.1 900-9D3C6-00CV-GA0 /900-9D3C6-00CV-
DA0Specifications
BlueField-3
IC
BlueField-3 E-Series - 16 Arm-Cores - 505MHz/2000MHz
Crypto Enabled with integrated BMC
Physical
Single-Slot FHHL Card Dimensions: 111.15mm x 167.65mm
Tall Bracket Dimensions: 121.0mm x 21.6mm
900-9D3C6-00CV-DA0 Only: Heatsink Dimensions (Length, Width, Height): 139.6mm x 92.7mm
x 10.2mm
Interfaces
SeeSupported Interfaces
PCI Express
Interface
Gen 5.0 SERDES @ 32.0GT/s, 16 lanes (4.0, 3.0, 2.0 and 1.1 compatible)
Optional: Additional PCIe x16 Gen 5.0 @ SERDES 32GT/s through the PCIe
auxiliary passive card and Cabline SA-II Plus harnesses
On-Board
Memory
Dual-channel with 20 DDR5 + ECC (128bit + 16bit ECC) for a total of
48GB@ 5200MT/s
40GB pSLC eMMC memory+ 128GB SSD
Networking
Connector
Dual-portQSFP112(copper and optical)
Data Rate
InfiniBand NDR200/HDR/HDR100/EDR/FDR/SDR
Ethernet
(Default Speed)
200/100/50/25/10 Gb/s
Protocol
Support
InfiniBand: IBTA v1.5a
Auto-Negotiation: NDR200 (2 lanes x 100Gb/s per lane) port, HDR (50Gb/s per lane) port,
HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port, FDR (14.0625Gb/s per lane),
1X/2X/4X SDR (2.5Gb/s per lane).
Ethernet: 200GAUI-4 C2M, 200GAUI-2 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4,
100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 ,
40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M,
25GAUI C2M, XLAUI C2M , XLPPI, SFI
Electrical
and
Thermal
Specificati
ons
Voltage: 12V
Electrical and thermal specifications are provided in "NVIDIA BlueField-3 DPUs and SuperNICs
Electrical and Thermal Specifications" document. You can access the document either by
logging into NVOnline or by contacting your NVIDIA representative.
Environmen
tal
Temperature Operational 0°C to 55°C
Non-operational
-40°C to 70°C
a
Humidity Operational 10% to 85% relative humidity
•
•
The DPU's maximum power consumption does not exceed 150Wand is split between the two
power sources as follows:
Up to 66W from the PCIe golden fingers (12V)
The rest of the consumed power is drawn from the external PCIe power supply
connector

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
