Nvidia BlueField-3 - Mechanical Interfaces; Encapsulation and Battery on SFG

81
Item # Board Components
9 U64
10 U65
11 U32
12 U33
13 See marked square
13.2.1 Mechanical Interfaces
The following figure lists the mechanical interfaces of the DPU controller.
Mechanical Interface
13.2.2 Encapsulation and Battery on SFG
Ensure that the battery remains unobstructed to allow access for replacement. Furthermore, avoid
any interference with the TTP. Note that the encapsulation is depicted as the maximum tolerance in
the SFG and is labeled as ENC.
