Nvidia BlueField-3 User Manual

62
Pin# Signal Name Wire Type Detailed
Description
AWG# Pin# on the
other end
19 GND GND BAR 19
20 PCIE_CPU_CX_10N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 20
21 PCIE_CPU_CX_10P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 21
22 GND GND BAR 22
23 PCIE_CPU_CX_9N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 23
24 PCIE_CPU_CX_9P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 24
25 GND GND BAR 25
26 PCIE_CPU_CX_8N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 26
27 PCIE_CPU_CX_8P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 27
28 GND GND BAR 28

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
