Nvidia BlueField-3 User Manual

67
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
5 No wire Micro coax 38 5
6 Reserved_06 Micro coax 38 6
7 Reserved_07 Micro coax 38 Reserved for future
expansion
7
8 Reserved_08 Micro coax 38 Reserved for future
expansion
8
9 GND GND BAR 9
10 PCIE_CX_CPU_0P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
10
11 PCIE_CX_CPU_0N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
11
12 GND GND BAR 12
13 PCIE_CX_CPU_1P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
13
14 PCIE_CX_CPU_1N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
14
15 GND GND BAR 15
