Jetson Nano Platform Adaptation and Bring-Up Guide DA_09361-002 | 22
Under the xusb_padctl Node
xusb_padctl settings for an OTG port are the same as for a host-only port except that
the mode must be otg.
For the example of J28, the USB 2.0 Micro B connector, create a pad/port node and
property list:
xusb_padctl: xusb_padctl@7009f000 {
...
pads {
usb2 {
lanes {
usb2-0 {
nvidia,function = "xusb";
status = "okay";
};
...
};
};
pcie {
lanes {
...
};
};
};
ports {
usb2-0 {
mode = "otg";
vbus-supply = <&p3449_vdd_usb_vbus>;
status = "okay";
};
...
};
};
Under the xHCI Node
The xHCI settings for an OTG port are the same as for a host-only port except for these
additional extcon settings:
• extcon-cables
OTG support. Must contain a pointer to the extcon-cable entry for the USB ID
pin. When the extcon cable state is 0, the OTG port transitions to the host role.
• extcon-cable-names
Must be id.
• #extcon-cells

Nvidia JETSON NANO Specifications

General

GPU	128-core NVIDIA Maxwell
Memory	4 GB LPDDR4
Storage	16 GB eMMC 5.1
Video Encode	4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265)
Dimensions	100 mm x 80 mm x 29 mm
CPU	Quad-core ARM Cortex-A57
Video Decode	4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30 (H.264/H.265)
Connectivity	Gigabit Ethernet
Display	HDMI 2.0
USB	USB 3.0
Other	GPIO, I2C, SPI, UART
Operating System	Linux
Power	5V
Camera	12x (MIPI CSI-2) DPHY lanes
