NVIDIA Jetson TX2/TX2i OEM Product Design Guide
JETSON TX2/TX2i OEM PRODUCT | DESIGN GUIDE | 20180618 3
Date
Description
- Added paragraph related to potential differences between hardware capabilities and support in released
sof tware.
References
- Added Jetson TX2/TX2i & Jetson TX1/TX2 Comparison & Migration App Notes.
Power
- Updated to to add separate Power-Up sequence figures and timing tables for Power-button cases & Auto-
power-on cases & note on differences between TX2i in P2597_B04 vs C02.
- Updated Auto-power-on section to remove alternate external solutions (kept mechanisms built-in to TX2 &
TX2i modules).
USB 3.0
- Added USB 2.0/3.0 dual-rolw (host/device) connection example.
- Updated Insertion Loss & max trace length guidelines to include device mode.
- Updated minimum AC cap value.
Ethernet
- Updated Magnetics connections figure to show individual caps to GND on CT inputs of magnetics device.
HDMI/DP
- Updated eDP/DP connection example figure to show only Tegra & Module pin names in Tegra block.
- Updated HDMI connection example figure to correctly align CLK/Data from Tegra to Connector & to show
only Tegra & Module pin names in Tegra block.
CSI
- Updated intro paragraph to indicate 3 quad or 6 dual lane cameras possible & added reference to
conf iguration table
WLAN/BT
- Updated Mating Antenna connector requirement to include both I-PEX & Hirose options.
Strapping
- Updated Power-on Strapping Breakdown table to show pull-up on module for Tegra RAM_CODE pins may
be present or not installed.
Pads
- Updated "Module Pins Pulled High on the Module Prior to CARRIER_PWR_ON Active" table to correct pull-
up on module f or RESET_OUT# pin.
