NVIDIA Jetson TX2/TX2i OEM Product Design Guide
JETSON TX2/TX2i OEM PRODUCT | DESIGN GUIDE | 20180618 61
11.0 WLAN / BT (INTEGRATED)  JETSON TX2 ONLY
Jetson TX2 integrates a Broadcom BCM4354 WLAN / BT solution. Tw o Dual-band antenna connectors are located on the
module. The requirements are in the Antenna Requirements table below . The UART interface is multiplexed and either route
these to the WLAN/BT device or to the connector pins for use on the carrier board. The default selection for the multiplexers is
to the WLAN/BT device.
Figure 33. Integrated WLAN / BT (Jetson TX2 only)
Jetson TX2
Tegra
SPI
WiFi / BT
QSPI_IO3
CAM
GPIO_CAM1
VDD_3V3_SYS
Load
Switch
VDD_1V8
RF
RF
Antenna
Connector #1
Antenna
Connector #2
SYS
MCPU_PWR_REQ
UART
GPIO_MDM5
GPIO_SW4
CONN
UART4_TX
UART4_RX
UART4_RTS_N
UART4_CTS_N
GPIO_PQ0
GPIO_PQ1
GPIO_PQ2
GPIO_PQ3
DMIC_HV
MUX_SEL
WIFI_EN
WIFI_WAKE_AP
BT2_WAKE_AP
BT_EN
AP2_WAKE_BT
DAP6_SCLK
DAP6_DOUT
DAP6_DIN
DAP6_FS
H10
H9
G10
G9
(Default)
Mux
UART3_TX
UART3_RX
UART3_RTS#
UART3_CTS#
SEL
SDMMC3
SDMMC3_CLK
SDMMC3_CMD
SDMMC3_DAT0
SDMMC3_DAT1
SDMMC3_DAT2
SDMMC3_DAT3
GPIO_SW3
Figure 34. Jetson TX2i connections related to the pins & interfaces used on Jetson TX2 for WLAN / BT
Jetson TX2i
Tegra
SPI
QSPI_IO3
CAM
GPIO_CAM1
SYS
MCPU_PWR_REQ
UART
GPIO_MDM5
GPIO_SW4
CONN
UART4_TX
UART4_RX
UART4_RTS_N
UART4_CTS_N
GPIO_PQ0
GPIO_PQ1
GPIO_PQ2
GPIO_PQ3
DMIC_HV
TEGRA_GPIO_SHUTDOWN
RDC_IN
BT2_WAKE_AP
H10
H9
G10
G9
UART3_TX
UART3_RX
UART3_RTS#
UART3_CTS#
SDMMC3
SDMMC3_CLK
SDMMC3_CMD
SDMMC3_DAT0
SDMMC3_DAT1
SDMMC3_DAT2
SDMMC3_DAT3
GPIO_SW3
B3 0
B2 9
B3 2
A32
A31
A30
To ON/OFF & Wake Circuitry
Tegra Package Daisy Chain Test
4.7kΩ
1.8V
SDIO_CLK
SDIO_CMD
SDIO_D0
SDIO_D1
SDIO_D2
SDIO_D3
