NVIDIA Jetson TX2/TX2i OEM Product Design Guide
JETSON TX2/TX2i OEM PRODUCT | DESIGN GUIDE | 20180618 85
PEX_[2:0]_REFCLK+/
Leave NC if not used
SATA
SATA_TX+/
Leave NC if not used.
SATA_RX+/
Connect to GND if SATA IF not used
DSI
DSI[3:0]_CK+/–
Leave NC any Clock lane not used.
DSI[3:0]_D[1:0]+/–
Leave NC any unused DSI Data lanes
CSI
CSI[5:0]_CK+/–
Leave NC any unused CSI Clock lanes
CSI[5:0]_D[1:0] +/–
Leave NC any unused CSI Data lanes
eDP/DP
DPx_TX[3:0] +/–
Leave NC any unused lanes
DPx_AUX_CH+/–
Leave NC if not used
DPx_HPD
Leave NC if not used
HDMI
DPx_TX[3:0] +/–
Leave NC if lanes not used for HDMI or DP
DPx_AUX_CH+/–
Leave NC if not used
DPx_HPD
Leave NC if not used
HDMI_CEC
Leave NC if not used

Nvidia JETSON TX2 Specifications

General

Storage	32 GB eMMC 5.1
Operating System	Linux for Tegra
GPU	NVIDIA Pascal architecture with 256 CUDA cores
Memory	8 GB LPDDR4
Connectivity	802.11ac WLAN, Bluetooth
Video Decode	4K @ 60 fps (HEVC), 4K @ 60 fps (H.264)
Power	7.5W | 15W
Camera	Up to 6 cameras (CSI)
USB	USB 3.0
Others	CAN, UART, SPI, I2C, GPIOs
CPU	Dual Denver 2 64-Bit CPUs + Quad ARM A57 CPUs
