Nvidia Quadro K5000 User Manual

Quadro K4000/K5000/K6000 SDI DU-05337-002_v01 | 26
Chapter 03 : Windows–Using the Graphics to SDI Control Panel
With applications that use video overlay or that maximize to a selected display, you can
also display the video full-screen on the SDI output.
Figure 3.3 Extended Desktop with Dualview Mode
The display and the SDI output do not need to be the same resolution and refresh rate.
Area displayed on primary display Area displayed on the SDI output
Application windows can be dragged
from one display to the other.
Use Full-Screen applications to present
a video overlay on the SDI output.

Nvidia Quadro K5000 Specifications

General

CUDA Cores	1536
Memory Size	4 GB
Memory Type	GDDR5
Memory Interface	256-bit
Memory Bandwidth	173 GB/s
Max Power Consumption	122 W
DirectX	11
OpenGL	4.5
Architecture	Kepler
GPU	GK104
Bus Interface	PCI Express 3.0 x16
Form Factor	Dual Slot
Display Connectors	2x DVI, 2x DisplayPort
Interface	PCIe 3.0 x16
Max Resolution	3840x2160
Outputs	DisplayPort + DVI-I
