Quadro K4000/K5000/K6000 SDI DU-05337-002_v01 | 3
02 NVIDIA GRAPHICS-TO-SDI
This chapter provides an overview of the NVIDIA graphics-to-SDI functionality,
described in the following sections:
 “Feature Overview” on page 3 lists the hardware connections, supported SDI formats,
and additional SDI support features of the NVIDIA Quadro SDI graphics card.
 “Installing and Preparing the NVIDIA Quadro SDI” on page 5 describes how to install
the NVIDIA Quadro SDI card and prepare it for use.
 “Operating NVIDIA SDI” on page 9 provides an overview of SDI operation.
Feature Overview
Graphics and BNC Connections
 Two BNC connections that can be configured as a single fill + key dual-link SDI
output, or up to two fill single-link SDI outputs
 One video monitoring output
 BNC connection for external sync signals
Supported SDI Signal Formats
 Standard Definition (SD) Modes
• 487i @ 59.95 Hz (SMPTE259) NTSC
• 576i @ 50.00 Hz (SMPTE259) PAL
 High Definition (HD) Modes
• 720p @ 23.97 Hz, 24.00 Hz, 25.00 Hz, 29.97 Hz, 30.00 Hz, and 50.00 Hz
• 720p @ 59.94Hz, 60.00 Hz (SMPTE296)
• 1035i @ 59.94 Hz, 60.00 Hz (SMPTE260)
• 1080i @ 50.00 Hz, 59.94 Hz, 60.00 Hz (SMPTE274)
