Table 10: External/Comms Mode Key Parameters
Parameter Default
Typ. 140
Tank
Range Description
Inlet Cut-Out Differential 15 25 15-100*
When inlet temperature reaches (Target Outlet Temperature - Cut
Out Differential), stop compressor.
Target Outlet Temperature 120 140 120-160 Target outlet water temperature from the heat pump.
Notes:
All parameters on the “congure“ screen. Service jumper required.
* Cut-Out Differential should always cut-out the demand at 115 degrees fahrenheit or lower. Adjust as needed as per Target Outlet Temperature.
Additional Parameter Conguration
Additional parameters are available to affect unit operation in all operating modes.
Table 11: Additional Parameters
Parameter Default Range Description
Drain Time 1 1-5 Number of minutes to sense water in the drain pan before suspending operation.
Purge Cut-Out 115 115-160 Outlet temperature that ends post purge after a heat demand ends.
Quiet Mode Off Special A 7-day schedule can be set to enforce "Quiet Mode" at certain times of day.
Note:
All parameters on the “congure“ screen. Service jumper required.
Note: The heat pump will allow itself to exceed the target outlet temperature if incoming water is too hot, ow is too low, and/or
during high capacity conditions, up to its maximum operating temperature for the current ambient conditions.
