Nyle e360 - Performance Specifications and Requirements

HeatWater.com | WaterService@nyle.com | (800) 777-6953 IM-e360-122023
6
IM-e360-122023 HeatWater.com | WaterService@nyle.com | (800) 777-6953
Performance Specications and Requirements
Table 1: e360 – Performance Specications
Heating and Cooling
Heating Capacity at 70°F
2
287,000 BTUs / hr
Heating Capacity at 10°F
2
98,000 BTUs / hr
Cooling Capacity at 70°F
1
211,000 BTUs / hr
Recovery Rate
3
380 Gallons / hr
Outdoor Temperature Operating Range 10-120°F
Water Inlet Operating Range 35-115°F
Water Outlet Operating Range
80-160°F
Mechanical
Water Side Maximum Flow
16 GPM
Available External Pressure Drop for Piping 15 Ft. Hd.
Maximum Water Side Pressure 150 PSIG
Minimum Tank Cycle Volume
4
157 Gallons
Design Air Side Flow 16,000 CFM
Available External Static for Ducting 1.5 In. W.C.
Refrigerant R513A
Typical Refrigerant Pressure High Side 130-395 PSIG
Typical Refrigerant Pressure Low Side 5-87 PSIG
Max Sound Pressure (Front / Left / Right / Rear)
5
78.5 / 70.2 / 70.7 / 79 dBA
Quiet Mode Sound Pressure
5
70.4 / 64.1 / 65.8 / 71.7 dBA
Salt Spray resistance Cabinet / Evap
9000 / 1000 hours
Notes:
¹ Cooling is incidental to heating operation and should typically be considered supplemental, not primary space cooling.
² Nominal heating performance is outdoor air at 50% RH, 140 degree fahrenheit outlet and 50 degree fahrenheit inlet water temps.
³
Recovery Rate assumes 70 degree fahrenheit outdoor temp, 140 degree fahrenheit storage temp and 50 degree fahrenheit inlet water temp.
4
Minimum Tank Cycle Volume is the min volume between tank sensor and heat pump inlet pipe, in the storage tank.
5
Sound Pressure measured 3' away 3' from ground, at max and quiet mode fan speeds, with ductless cowl installed.
