DOC-13000 Rev. E 7–21
Connex500/350 User Guide
11. Removethecleaningmaterialsfromtheprinterandclosethecover.
12. Selecttheconfirmationcheckboxesinthewizardscreenandclick
Next.
Thehead‐purgecyclebegins.Whenthisiscomplete,thefinalwizard
screenappears.
Figure 7-22: Head cleaning wizard—final screen
13. ClickDonetoclosethewizard.
Pattern Test
Thepatterntestisthebasicverificationoftheprinter’sabilitytoproduce
qualitymodels,sinceitdemonstratestheconditionofthenozzlesinthe
printheads.Makesure,therefore,thatyouperformthistestweekly,and
wheneveryoususpectaprintingproblem.
To perform the pattern test:
1. Makesurethatthebuildtrayisempty.
2. Prepareasheetofpinkpaper—A‐4orLettersize.
3. IntheConnexprinter,tapethepinkpapertothesurfaceleftofthe
buildtray.
4. Press
F3,oropentheOptionsmenuandselectPattern Test.
Figure 7-23: Pattern Test confirmation
5. Ifthebuildtrayisnotclear,clickNointhefollowingdialogbox.
Thislowersthebuildtray,sothatmodelsonthetrayarenotdamaged.
Figure 7-24: Build tray (Z) level adjustment
TheConnexprinterprintsaseriesoflinesonthetestpaper.
