DOC-13000 Rev. E 7–7

Connex500/350 User Guide

Printer

Interface

Color Key

Thebackgroundcolorsintheprinterindicatorfieldstellyouataglance

whetherornotthevalueoritemissuitableorreadyforprinting.

• Green—suitable/readyforprinting

Forexample,infigure 7‐4:

 Ambient—Theambienttemperatureoftheprintingchamberis

withintheacceptablerange.

 HeadsLiquid—Thelevelofmodelandsupportmaterialintheprint‐

blockreservoirisOK.

 HeadsVacuum—Thevacuumlevelinthesystemiswithinthe

acceptablerange.

• Red—notsuitableforprinting(orindicatesawarning)

Forexample,infigure 7‐4:

 Waste—Theweightofthewastecontainerisgrams,morethan

allowedwhenbeginningaprintjob.(See“ReplacingtheWaste

Container”onpage 7‐62.)

• Blue—notready

Forexample,infigure 7‐4:

 UVlamps—TheUVnoton.

 Heads(°C)—Theheadshavenotreachedthetemperaturerequired

forprintingmodels(inprintingmode).

Thecolorofthematerialcartridgesdisplayedintheprinterinterface

indicateswhichcartridgesareactiveforthecurrent(ornext)printjob.

• Blue—activecartridges

• Gray—reservecartridges
