OCULUS Pentacam User Manual

9 Scan Menu
14 / 29 Instruction Manual Pentacam® / Pentacam HR® (G/70700/0109/en)
9.2 Information for recording Scheimpflug images
Specific instructions for the Pentacam HR
Type of examination Examination mode Images Automatic measure-
ment
Notes
Topography 3D scan 25-50 Yes
Pachymetry 3D scan 25-50 Yes
Analysis of the anterior
chamber
3D scan 25-50 Yes Do not apply mydriatic drops.
Artificial lenses (gener-
al)
Enhanced dynamic
(for HR in the "3D scan"
examination mode)
15 Yes If the pupil is insufficiently dilated, apply
mydriatic drops
Use 3D scan for measurements.
Measuring functions 3D scan 25-50 Yes If the pupil is insufficiently dilated, apply
mydriatic drops
Densitometry 3D scan
Enhanced dynamic
25-50
5-15
No Use the same number of images to en-
able a progress check.
Type of examination Examination mode Images Automatic measure-
ment
Notes
IOLs, ICLs, PIOLs 3D scan for PIOLs, possi-
bly longer exposure
25-50 Yes If the pupil is insufficiently dilated, apply
mydriatic drops

OCULUS Pentacam Specifications

General

Measurement Time	Less than 2 seconds
Corneal Coverage	Up to 12 mm
Software	Pentacam Software
Data Transfer	USB
Corneal Topography	Yes
Display	External monitor required
Measurement Principle	Scheimpflug imaging
Camera	Rotating Scheimpflug camera
Light Source	Blue LED
Pachymetry	Yes
Anterior Chamber Analysis	Yes
Imaging Principle	Scheimpflug imaging
Fixation	Internal
Power Supply	100-240 V, 50/60 Hz
Resolution	High resolution
Lens Density Measurement	Yes
Dimensions	Varies depending on model and configuration
Weight	Varies by model, check manufacturer specifications
Number of Images	25 or 50
