OCULUS Pentacam User Manual

12 Transferring Measurement Results
22 / 29 Instruction Manual Pentacam® / Pentacam HR® (G/70700/0109/en)
Note
Requirements for transferring data to another PC:
 A software licence purchased from an authorised dealer. This licence includes instal-
lation instructions and a Licence-Key.
 The Pentacam program must be installed on the other PC. If the program is updated
on the Pentacam PC (sender), the program on the other PC (recipient) must also be
updated.
12.2 Importing patient data
Import the patient and examination data you have received into your Pentacam software.
Î In Patient Data Management (fig. 7-1, page 8), click [Import]
The following dialog box appears:
Fig. 12-2: Import
Î Select the option "U12".
Î Click the button under "File".
Î Look for the exported file in the selected folder.
Î Open the exported file.
Î Click [Import].
The imported files are marked in the Patient Data Management menu.

OCULUS Pentacam Specifications

General

Measurement Time	Less than 2 seconds
Corneal Coverage	Up to 12 mm
Software	Pentacam Software
Data Transfer	USB
Corneal Topography	Yes
Display	External monitor required
Measurement Principle	Scheimpflug imaging
Camera	Rotating Scheimpflug camera
Light Source	Blue LED
Pachymetry	Yes
Anterior Chamber Analysis	Yes
Imaging Principle	Scheimpflug imaging
Fixation	Internal
Power Supply	100-240 V, 50/60 Hz
Resolution	High resolution
Lens Density Measurement	Yes
Dimensions	Varies depending on model and configuration
Weight	Varies by model, check manufacturer specifications
Number of Images	25 or 50
