18 Technical Specifications / Minimum PC Requirements
28 / 29 Instruction Manual Pentacam® / Pentacam HR® (G/70700/0109/en)
18 Technical Specifications /
Minimum PC Requirements
Measuring equipment
Measuring range
Power supply
Other information
Camera Digital CCD camera
Light source Blue LEDs (475 nm, UV-free)
Speed 50 images in 2 seconds, 500 measuring
points (HR: 2760) per recorded image
Number of evaluated measuring points Max. 25,000 (HR: max. 138,000)
Dimensions H x W x D 535 x 280 x 360 mm
Weight 9 kg
Curvature: 3 to 38 mm
9 to 99 dpt
Accuracy ± 0.2 dpt
Reproducibility ± 0.2 dpt
Working distance 80 mm
Mains connection 100 - 240 V AC, 50 - 60 Hz
Power input 60 W
Power output 24 V, 2.1 A
Fuses Integrated overcurrent shut-off
CE marking CE 0123
Contraindications None noted
Lifecycle expectancy Up to 10 years
