OCULUS Pentacam User Manual

1 Scope of Delivery
Instruction Manual Pentacam® / Pentacam HR® (G/70700/0109/en) 1 / 29
1Scope of Delivery
[We reserve the right to change the scope of delivery in line with ongoing technical
development]
Component Order number
Pentacam
Pentacam HR
70700
70900
 Pentacam mounted on an x-y-z mobile unit 70518
 Head and chin rest
 Plate for mounting on a refraction unit or table
(Dimensions 28 cm x 36 cm)
70517-01-006
 Power supply, input 100 V-240 V, output 24 V, 2.1 A, Hitron HES 49 05150150
 USB cable 70900-07-001
 Licence key (dongle) 70740
 Testing log, electrical safety
 Instruction Manual G / 70700
(HR): G / 70900
 Dust protection cover 60100-5/1
 Paper for chin support 65313
 Software package and books
 Windows(tm) software package and operating instructions
 Dark sheet 027070000006
Standard software module Order number
 Software module: Pachymetry 70721
 Software module: Densitometry 70722
 Software module: 3D chamber analysis 70723
 Software module: Corneal topography, front and rear surface 70724
Optionally available modules Order number
 Colour printer 70520
 Simulation program for adjusting contact lenses 70726
 Simulation program for fitting phakic IOLs, incl. age simulation
(Pentacam HR only)
70928

OCULUS Pentacam Specifications

General

Measurement Time	Less than 2 seconds
Corneal Coverage	Up to 12 mm
Software	Pentacam Software
Data Transfer	USB
Corneal Topography	Yes
Display	External monitor required
Measurement Principle	Scheimpflug imaging
Camera	Rotating Scheimpflug camera
Light Source	Blue LED
Pachymetry	Yes
Anterior Chamber Analysis	Yes
Imaging Principle	Scheimpflug imaging
Fixation	Internal
Power Supply	100-240 V, 50/60 Hz
Resolution	High resolution
Lens Density Measurement	Yes
Dimensions	Varies depending on model and configuration
Weight	Varies by model, check manufacturer specifications
Number of Images	25 or 50
