9600 Periodic Maintenance Procedure 00-880606-02
Page 13
1. SAFETY INSPECTIONS
1.1 MECHANICAL INSPECTIONS
BRAKES
INSPECT WIG WAG & BRAKE
1. Engage the Wig-Wag brake.
2. Verify that the Wig-Wag brake locks the forward mechanics in any position within the range of
motion (11° either side of center position).
INSPECT FLIP FLOP & BRAKE
1. Tighten the Flip Flop brake and verify that the Flip Flop does not move.
INSPECT C-ARM ORBITAL BRAKE
1. Engage the brake by turning the brake handle 90°.
2. Verify that the brake is engaged and that the C-Arm will not move.
INSPECT CROSS-ARM BRAKE
1. Engage the brake.
2. Verify that the brake is engaged and that the Cross-Arm will not move. The brake handle should
tighten the brake with a minimum of travel. Excessive movement may indicate brake wear.
3. Refer to the Non-Motorized Movements, Cross-Arm Motion section in these procedures if the
Cross-Arm brake requires adjustment.
LOCKS
MOBILE C-ARM
1. Select the LOCK mode:
• Systems with center pivot steering: the LOCK mode is both the front-locked (front-
depressed) and
the rear-locked (rear-depressed) pedal positions.
• Most older systems without center pivot steering: the LOCK mode is the rear-locked (rear-
depressed) pedal position only. However, some
older systems have the LOCK mode in the
front-locked position.
Attempt to push the C-Arm and verify that the caster/wheel assemblies are locked in place; the
casters should not pivot and the wheels should not roll.
