9600 Periodic Maintenance Procedure 00-880606-02
Page 40
PM FORM COMPLETION
Verify that the PM Form has been completely and correctly filled out. Make sure to obtain a customer
signature.
PAINT KITS
PART NUMBER DESCRIPTION
900524-11 Paint Kit, Elite Gray, Texture
900524-12 Paint Kit, Rhinestone, Texture
900524-13 Paint Kit, Windswept, Texture
TORX CRESTCUP TORQUE SPECIFICATIONS
TORX SCREW
SIZE
NOMINAL
TORQUE VALUE
ACCEPTABLE
RANGE
4-40 6 lbs./in 5-8 lbs./in
6-32 15 lbs./in 13-16 lbs./in
8-32 22 lbs./in 21-24 lbs./in
10-32 30 lbs./in 28-31 lbs./in
LUBRICATION AND ADHESIVES
•
Alcohol Prep Pads
•
Permatex Industrial Super Lube P/N - 88-299483-00 (Collimator)
•
Permatex Super Lube Spray P/N - 88-299485-00 (Lift Chains)
•
Mobile Synthetic SH-32 P/N - 88-299481-00 (for Gears)
•
Dow Corning BR2+ P/N - 88-299477-00 (Flip Flop Bearing)
GE OEC Medical Systems, Inc.
384 Wright Brothers Drive
Salt Lake City, Utah 84116
U.S.A.
(801) 328-9300
