C5550 MFP User’s Guide
Maintenance > 128
2. Press the cover release (a) and open the MFP’s top cover
(b) fully.
Cover Release.eps
3. Note the positions of the four cartridges. It is essential
that they go back in the same order.
ID Order.eps
b
a
WARNING!
If the MFP has been powered on, the fuser will be hot.
This area is clearly labelled. Do not touch.
1
2
3
4
1. Cyan cartridge 2. Magenta cartridge
3. Yellow cartridge 4. Black cartridge
