C5550 MFP User’s Guide
Troubleshooting > 157
exposure to room lighting while you check the remaining
areas for jammed sheets.
11. Open the rear exit tray (5) and check for a sheet of paper
in the rear path area (6).
Rear paper jam.eps
Pull out any sheets found in this area.
If the sheet is low down in this area and difficult to remove,
it is probably still gripped by the fuser. In this case raise
the top cover, reach around and press down on the fuser
pressure release lever (7).
Jams 3_1.eps
12. If you are not using the rear exit tray, close it once paper
has been removed from this area.
6
5
7
To Next Page
