3
3-67 Color Editor
C9800 Color Guide - 67
N
OTE: Adjust points in this way only after you have entered the Dot Gain and
Brightness values.
For greater precision, type percentages in the Input and Output fields or use the arrow
keys on the keyboard to adjust the curve. To use the arrow keys, you must first click the
curve to establish an anchor point that serves as a reference.
9. For an output profile, set maximum densities of the C, M, Y, and K channels.
Enter the maximum densities, called D-Max values, of individual colors for profiles
that support density settings. D-Max settings are not available when you edit
Simulation profiles in Master mode.
10. When you are finished, click Save and enter a name for the new profile.
The new custom profile is saved to the Fiery with the new name. If you edit one of the
press standard targets (for example, SWOP-Coated, DIC, or Euroscale), consider
including the original name as part of the new target name (for example, DIC-new) to
help you remember the source of the new target.
NOTE: Preset default profiles are locked and must be saved with a new name.
For Mac OS computers, custom profiles must be linked to one of the ten predefined
custom profile names (Simulation-1 through Simulation-10 for Simulation, or
Output-1 through Output-10 for Output) to be accessible from the printer driver.
Create as many custom profiles as you want, but a maximum of ten are available from
A curve with this shape
makes a color appear
lighter by reducing
density in the midtones.
A curve with this shape
makes a color appear
darker by adding density
in the midtones.
A curve with this shape
increases contrast.
