44292401TH Rev.1
120 /
Oki Data CONFIDENTIAL
ADJUSTMENT/SETTING
13.2 FAX MAINTENANCE
See P.122
13.3 ADJUST
See P.124
TRANSFER POWER SIMPLEX PASS PLAIN PAPER
P. 1 2 0
THICK1
THICK2
POSTCARD
ENVELOPE
LABEL
DUPLEX PASS PLAIN PAPER
IMAGE ADJ PRAM
MAINTENANCE
Ref.
page
14. SERVICE MODE
14.1 SERVICE MODE entry procedure
NOTE
Ensure appropriate security for the Service Mode entry procedure. It should
NEVER be given to any unauthorized person.
A. Procedure
1. On the initial screen, press the following keys in this order.
Select o Stop/Reset o 0 o 0 o Stop/Reset o 0 o 1
B. Exiting
Press the Stop/Reset key.
14.2 SERVICE MODE function tree
NOTE
The function tree is shown to comply with the format displayed on the screen.
<*1>: If engine is EU type, this item doesn’t display.
<*2>: Displayed only when the lower feeder unit is installed.
SERVICE MODE
Ref.
page
SERVICE’S CHOICE TX SPEED P. 1 2 2
RX SPEED P. 1 2 2
TX LEVEL P. 122
RX LEVEL P.122
DTMF LEVEL P. 1 2 2
CNG LEVEL P. 123
CED LEVEL P. 1 2 3
ECM MODE P. 1 2 3
CODING SCHEME P.123
TONER EMPTY REPORT P. 1 2 3
PROTOCOL REPORT P. 1 2 3
GDI TIMEOUT P. 1 2 3
TWAIN TIMEOUT P.124
ENERGY SAVE MODE <*1> P.124
ENABLE WARNING T/C LOW P.124
I/C LOW P.124
13. SERVICE MODE
13.1 SERVICE MODE entry procedure
13.2 SERVICE MODE function tree
12.3 ADJUST
12.2 FAX MAINTENANCE
14. SERVICE MODE
14.1 SERVICE MODE entry procedure
NOTE
Ensure appropriate security for the Service Mode entry procedure. It should
NEVER be given to any unauthorized person.
A. Procedure
1. On the initial screen, press the following keys in this order.
Select o Stop/Reset o 0 o 0 o Stop/Reset o 0 o 1
B. Exiting
Press the Stop/Reset key.
14.2 SERVICE MODE function tree
NOTE
The function tree is shown to comply with the format displayed on the screen.
<*1>: If engine is EU type, this item doesn’t display.
<*2>: Displayed only when the lower feeder unit is installed.
SERVICE MODE
Ref.
page
SERVICE’S CHOICE TX SPEED P. 1 2 2
RX SPEED P. 1 2 2
TX LEVEL P. 122
RX LEVEL P.122
DTMF LEVEL P. 1 2 2
CNG LEVEL P. 123
CED LEVEL P. 1 2 3
ECM MODE P. 1 2 3
CODING SCHEME P.123
TONER EMPTY REPORT P. 1 2 3
PROTOCOL REPORT P. 1 2 3
GDI TIMEOUT P. 1 2 3
TWAIN TIMEOUT P.124
ENERGY SAVE MODE <*1> P.124
ENABLE WARNING T/C LOW P.124
I/C LOW P.124
