ADJUSTMENT/SETTING
14.3.14 ENERGY SAVE MODE
14.3.15 ENABLE WARNING
A. T/C LOW
B. I/C LOW
14.4 ADJUST
• Different adjust items are applicable and the corresponding adjust values become valid
according to the specific sub-function of the main function (Copy, Fax, Twain, or
NetScan) as detailed below.
Function
• To specify the time for TWAIN time out.
Use
Setting/
procedure
• The default setting is 6 min.
2min / 4min / “6min” / 8min / 10min / 12min / 14min / 16min / 18min
Function
• Set weather to activate Energy Save mode when print job receiving or panel operation
have not been made for a given period.
Use
Setting/
procedure
• The default setting is ON.
“ON” / OFF
Function
• Specifies whether or not a warning appears when the toner is about to run out.
Use
Setting/
procedure
• The default setting is ON.
“ON” / OFF
Function
• Specifies whether or not a warning appears when the print unit is about to reach the end
of its service life.
Use
Setting/
procedure
• The default setting is ON.
“ON” / OFF
Function
Copy Fax Twain Scan
Adjust item CIS ADF CIS ADF CIS ADF CIS ADF
CIS MAIN ZOOM {{{{
CIS SUB ZOOM { X {
CIS MAIN REGIST { X { X { X { X
CIS SUB REGIST { X { X { X { X
ADF SUB ZOOM X { X {
ADF MAIN REG X { X { X { X {
ADF SUB REG X { X { X { X {
Function
• To adjust for variations in the accuracy of IR parts and their mounting accuracy by
varying the scanning zoom ratio in the main scanning direction.
Use
• When the MFP board has been replaced.
• When the scanner unit has been replaced.
NOTE
• When the MFP board is replaced, the setting value is cleared. Re-entering a new
setting value is necessary.
Adjustment
Specification
• Adjust the width of D in the copy of the test pattern1 so that the following specification
is met.
• 100 ± 0.5% (Zoom Ratio = Full Size:100%)
Adjustment
Range
• The default setting is 0%.
• -2.0% ~ “0%” ~ +2.0%
• Step: 0.2%
Setting/
Procedure
1. Print the test pattern1.
See P.131
2. Enter the [ADJUST] menu in the service mode.
3. Select [CIS MAIN ZOOM] of [ADJUST] and press the Select key.
4. Place the test pattern1 on the Original Glass and make a test copy.
NOTE
• The test pattern1 should be positioned vertically.
• Use A4 or Letter paper loaded into tray1 to make the test copy.
5. Check that the width of D in the copy of the test pattern1 meets the specification.
Calculation: (1 - Width of D in the document y Width of D in the copy) u 100
If the width of D is out of specification, adjust it according to the following procedure.
6. Press the Select key.
7. Using the S/T key, change the setting value and then press the Select key.
8.
Place the test pattern1 on the Original Glass. Then, make a test copy again and check
it.
Adjustment
Instructions
• If the width of D in the test pattern is longer than the specified width
..... Decrease the setting.
• If the width of D in the test pattern is shorter than the specified width
..... Increase the setting.
