Oki MC160MFP - Page 123

44292401TH Rev.1
122 /
Oki Data CONFIDENTIAL
ADJUSTMENT/SETTING
14.3 SERVICE’S CHOICE
14.3.1 TX SPEED
14.3.2 RX SPEED
14.3.3 TX LEVEL
14.3.4 RX LEVEL
14.3.5 DTMF LEVEL
Function
• Transmit start speed setting. Choose the mode from among the following.
Use
Setting/
procedure
• The default setting is V.34 33600bps.
“V.34”: “33600”, 31200, 28800, 26400, 24000, 21600, 19200, 16800
V.17: 14400, 12000, 9600, 7200
V.29: 9600, 7200
V.27: 4800, 2400
Function
• Reception start speed setting. Choose the mode from among the following.
Use
Setting/
procedure
• The default setting is V.34 33600bps.
“V.34”: “33600”, 31200, 28800, 26400, 24000, 21600, 19200, 16800
V.17: 14400, 12000, 9600, 7200
V.29: 9600, 7200
V.27: 4800, 2400
Function
• PSK/FSK signal output level.
Use
Setting/
procedure
• The default setting is -9 dBm.
-17 to -10 dBm ~ “-9 dBm” ~ -8 to -2 dBm
Function
• Reception sensitivity level.
Use
Setting/
procedure
• The default setting is -43 dBm.
-49 to -44 dBm ~ “-43 dBm” ~ -42 to -36 dBm
Function
• Dual tone output level.
Use
Setting/
procedure
• The default setting is -9 dBm.
-17 to -10 dBm ~ “-9 dBm” ~ -8 to -2 dBm
13.3.2 RX SPEED
13.3.3 TX LEVEL
13.3.4 RX LEVEL
13.3.5 DTMF LEVEL
13.3 SERVICE’S CHOICE
13.3.1 TX SPEED
SERVICE MODE
Ref.
page
FUNCTION PAPER FEED TEST TRAY1
P. 1 31
TRAY2 <*2>
PRN TEST PATTERN TRAY1 PATTERN1
P. 1 31
PATTERN2
TRAY2 <*2> PATTERN1
PATTERN2
ADF FEED TEST P. 1 32
COPY ADF GLASS P. 132
FAX RES. COPY TEST P. 1 32
SCAN TEST P. 132
SOFT SWITCH P.132
REPORT SERVICE DATA LIST P.1 32
ERROR CODE LIST P. 134
T.30 PROTOCOL LIST P. 1 34
ADMIN. REGISTRATION P. 135
FIXED ZOOM CHANGE REDUCTION2
P. 1 35
REDUCTION1
EXPANSION1
EXPANSION2
FACTORY TEST SIGNAL TEST
P. 1 35
RELAY TEST
SENSOR TEST
DIAL TEST
VOLUME TEST
PANEL BUZZER TEST
RAM TEST
CLEAR DATA SRAM CLEAR P. 1 35
MEMORY CLEAR P.1 35
