Paper handling > 34
Set the Paper Thickness lever for overall paper thickness as follows:
Carbon paper or
Pressure- sensitive
paper (40 gsm)
See below
2 part X
3 part X
4 part X
5 part X
6 part X
7 part X
OVERALL PAPER THICKNESS LEVER POSITION
0.06 - 0.10 mm 1
0.11 - 0.15 mm 2
0.16 - 0.20 mm 3
0.21 - 0.25 mm 4
0.26 - 0.30 mm 5
0.31 - 0.35 mm 6
0.36 - 0.40 mm 7
0.41 - 0.45 mm 8
0.46 - 0.50 mm 9
0.51 - 0.53 mm 10
NOTE
> Printing with lever positions 5 – 10 is not guaranteed.
> If the lever position does not suit the paper thickness, paper feeding and
printing may not work properly.
> Do not print bankbooks to avoid possible pin breakage/ribbon snagging.
> When lever positions 5 - 10 are selected, printing quality for carbon paper
may decline resulting in illegible characters for example.
PAPER TYPE
LEVER POSITION
1 2 3 4 5 6 7 8 9 10 REMARKS
To Next Page
