10 – Technical Specifications
67
4-Analog Output Module
Function
Function:
Generation of 1 to 4 analog values.
Capacity:
■ 4 independent opto-isolated outputs 4-20mA
(recopy detector, minimum, maximum, or
average of a detector group).
■ Resistance of maximum load 500 .
Logic inputs:
2 additional logic inputs (dry contacts).
Connections:
■ Screwed terminals.
■ Connector detachable without cutting the line
■ Tightening torque: 0.5-0.6 Nm.
■ Cable: 2.5 mm² maximum.
Consumption:
■ < 5 mA with the 4 lines at stop.
■ < 36 mA for an activated line.
■ < 130 mA for the 4 activated lines.
Assembly:
Snap-on on DIN rail.
Dimensions:
125 x 165 x 60 mm.
