38
MX 43
User Manual
4- or 8-Relay Modules
Figure 38: 4- or 8-relay module connections
If this module is the last on the line, do not forget to set the switch
marked EOL resistor/resistance FDL to ON.
16-Logic Input Module
Figure 39: 16-logic input module connections.
If this module is the last on the line, do not forget to set the switch
marked EOL resistor/resistance FDL to ON.
4- or 8-output contacts
RTC (250VAC or 30 V
DC – 2A)
Supervised contact
To next module
To MX 43
or previous module
To next module
To MX 43
or previous module
Supervised contact
Supervised contacts
Supervised
contact
