MX 43
User Manual
Configuring sensors
Downloading the configuration
The MX 43 uses 256 external addresses (line #1 channel #1, to line #8
channel #32) and 8 analog channels for which the addresses are located from
257 to 264.
With the automated system, it is possible to send 264 (256 + 8) Modbus
requests, where the address field is numbered from 1 to 264 in order to
download the configuration of each sensor into the internal memory.
As a result of the operating functionality, it is only possible to repatriate the
data of a single sensor for interrogation.
If a sensor is stated at the address mentioned, the MX 43 sends the number
of data words requested; always from data #1: NAME OF ANALOG SENSOR,
at data #x.
If there is no information at the address mentioned, the MX 43 sends back 0.
1
Line 1 Sensor 1
32
Line 1 Sensor 32
33
Line 2 Sensor 1
64
Line 2 Sensor 32
65
Line 3 Sensor 1
96
Line 3 Sensor 32
97
Line 4 Sensor 1
128
Line 4 Sensor 32
129
Line 5 Sensor 1
160
Line 5 Sensor 32
161
Line 6 Sensor 1
192
Line 6 Sensor 32
193
Line 7 Sensor 1
224
Line 7 Sensor 32
225
Line 8 Sensor 1
256
Line 8 Sensor 32
257
Analog line unit number 1
264
Analog line unit number 8
Sensor addresses
