4
Figure 2: Example of an MX 43 configuration using different analog and digital detectors
as well as digital modules.
MX 43
Configuring PC with the
COM 43 application
Analog
detectors
Digital detectors
2 logic
inputs
Analog recorders
Module
4 * 4-20 mA outputs
Module 8 relays
Module
logic input
Module 4 relays
16 logic
inputs
8 analog
inputs
External
power supply
USB
link
