Olivetti d-Copia 3003MF - Page 107

2MH/2MJ/2MK/2ML
1-4-10
6000 Broken Fuser heater wire
The fuser temperature does not rise
after the Fuser heater has been
turned on.
Poor contact in
the fuser therm-
istor connector
terminals.
Reinsert the connector (See page 1-5-
32).
Poor contact in
the Fuser heater
connector termi-
nals.
Reinsert the connector (See page 1-5-
32).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Fuser thermal
cutout triggered.
Replace the fuser unit (See page 1-5-
32).
Fuser heater
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Broken Fuser
heater wire.
Replace the fuser unit (See page 1-5-
32).
6020 Abnormally high fuser thermistor
temperature
Fuser thermistor detects abnormally
temperature.
Shorted fuser
thermistor.
Replace the fuser unit (See page 1-5-
32).
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
6030 Broken fuser thermistor wire
Input from fuser thermistor is 0 (A/D
value).
Poor contact in
the fuser therm-
istor connector
terminals.
Reinsert the connector (See page 1-5-
32).
Broken fuser
thermistor wire.
Replace the fuser unit (See page 1-5-
32).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Fuser thermal
cutout triggered.
Replace the fuser unit (See page 1-5-
32).
Fuser heater
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Broken Fuser
heater wire.
Replace the fuser unit (See page 1-5-
32).
Code Contents
Remarks
Causes
Check procedures
/corrective measures
Service Manual Y113860-1
