Olivetti d-Copia 3003MF - Detaching and Refitting the MP Paper Feed Roller

2MH/2MJ/2MK/2ML
1-5-10
(3) Detaching and refitting the MP paper feed roller
Procedure
1. Open the front cover.
2. Pull the MP feed holder (lever) down. :1
3. Slide the MP feed holder. :2
4. Remove the MP paper feed roller. :3
Figure 1-5-13
2
3
MP feed
holder
(Lever)
Front cover
MP paper feed
roller
MP paper feed roller
1
Service Manual Y113860-1
