Olivetti d-Copia 3003MF - Optical Section; Scanner Unit

2MH/2MJ/2MK/2ML
2-1-6
2-1-3 Optical section
(1) Scanner unit
Figure 2-1-10 Scanner unit
1
3
7
8
9
5
10
4
6
2
1. ISU top frame
2. ISU bottom frame
3. Contact glass
4. DP contact glass
5. Size indicator plate
6. ISU belt
7. ISU shaft
8. ISU gear 63/32
9. ISU motor
10. Image scanner unit (ISU)
Service Manual Y113860-1
