2MH/2MJ/2MK/2ML
1-5-15
5. Release three clamps and then remove
the wires.
Figure 1-5-18
6. Remove two screws.
Figure 1-5-19
Wires
Wires
Clamp
Clamp
Clamp
Screw Screw
Screw
Screw
Y113860-1 Sevice Manual
