2MH/2MJ/2MK/2ML
2-2-2
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Control PWB PARTS MAIN PWB ASSY FS SP
1 Control PWB PARTS MAIN PWB ASSY FS SP EU
2 Power source PWB PARTS SWITCHING REGULATOR 230V SP
3 High voltage PWB HIGH VOLTAGE UNIT
4 Operation panel PWB PARTS PANEL PWB ASSY SP
5 APC PWB -
6 PD PWB -
7 Zener PWB -
8 Scanner PWB PARTS SCANNER PWB ASSY SP
9 CCD PWB -
10 LED drive PWB -
11 FAX control PWB PARTS MAIN FAX ASSY U SP
11 FAX control PWB PARTS MAIN FAX ASSY E SP
12 LED PWB -
13 RFID PWB (RFPWB) PARTS PWB RFID ASSY SP
