Olivetti d-Copia 3003MF - Page 30

2MH/2MJ/2MK/2ML
1-2-5
11. Remove the tape A.
12. Move the lock lever to the position of
release.
* : When turning on power if the lock lever is
not released, the error message is displayed.
13. Close the DP.
14. Remove eight tapes B.
Figure 1-2-7
Tapes B
Tapes B
Tapes B
Tapes B
Tape A
Lock lever
Y113860-1 Sevice Manual
