Olivetti d-Copia 3003MF - Page 41

2MH/2MJ/2MK/2ML
1-3-10
U000
Item No. Description
No. Items Description
(9) Maintenance
Log
# Count. Item
Remembers 1 to 8 of
occurrence of
replacement. If the
occurrence of the
previous replace-
ment of toner con-
tainer is less than 8,
all of the occurrences
of replacement are
logged.
The total page count
at the time of the
replacement of the
toner container.
Code of mainte-
nance replacing item
(1 byte, 2 categories)
First byte
(Replacing item)
01: Toner container
02: Maintenance kit
Second byte
(Type of replacing
item)
00: Black
01: MK-1130/1140
MK-1132/1142
(10) Unknown Toner
Log
# Count. Item
Remembers 1 to 5 of
occurrence of
unknown toner detec-
tion. If the occurrence
of the previous
unknown toner detec-
tion is less than 5, all
of the unknown toner
detection are logged.
The total page count
at the time of the
[Toner Empty] error
with using an
unknown toner con-
tainer.
Unknown toner log
code (1 byte, 2 cate-
gories)
First byte
01: Fixed (Toner con-
tainer)
Second byte
00: Fixed (Black)
(11) Counter Log
Comprised of
three log coun-
ters including
paper jams, self
diagnostics
errors, and
replacement of
the toner con-
tainer.
(f) Paper jam (g) Self diagnostic
error
(h) Maintenance item
replacing
Indicates the log
counter of paper jams
depending on loca-
tion.
Refer to Paper Jam
Log.
All instances includ-
ing those are not
occurred are dis-
played.
Indicates the log
counter of self diag-
nostics errors
depending on
cause.
(See page 1-4-4)
Example:
C6000: 4
Self diagnostics
error 6000 has hap-
pened four times.
Indicates the log
counter depending on
the maintenance item
for maintenance.
T: Toner container
00: Black
M: Maintenance kit
00: MK-1130/1140
MK-1132/1142
Example:
T00: 1
The toner container
has been replaced
once.
Service Manual Y113860-1
