1-
2-7
1. Pull the cassette from the printer out.
(45 ppm model only)
2. Push the bottom plate down.
Figure 1-2-10
(Common)
3. Turn the cassette size dial
so that the
size of th
e paper you are going to use
appears in the cassette size window.
Figure 1-2-11
4. Push the lock lever on the left
side
g
uide and slide to the desired pape
r
size.
Figur
e 1-2-12
(45 ppm model only)
Botom plate
Cassette
Cassette size dial
Cassette size window
Paper didth guide
Paper width guide
Lock lever
To Next Page
