Olivetti SIMPLE_WAY User Manual

CHAPTER 14
Reference Part Description
1 Paper guide Guides the paper fed into the printer.
2Paper support (ASF) Supports the paper loaded.
3 Extractible cover
of the exposure bed
Cover of the scanner. Can be removed to scan bulky documents
(such as books).
4 Front panel Used to switch the printer ON and OFF and to control print, copy
and scanning operations.
5 Front hatch To access the compartment containing the print cartridges.
6 Paper tray Collects the paper printed that is ejected from the printer.
7 Exposure bed Place the document or the photo with the side to be copied or to
be scanned facing down. See "Positioning of the document on
the exposure bed".
8 Scanning unit To place the original on the exposure bed.
9 Power connector Connect the power cable of the external universal power supply
unit, furnished with the product, to the printer.
Then connect the other end of the external power supply unit
with the mains cable to a grounded electrical outlet.
note: Connect first of all the cable to the printer and then to the
outlet.
10 High speed USB
interface
Connect the USB cable (not included) to the printer for
connection to the computer. Connect the other end of the cable
to the USB port on the computer.
11 Support for cartridges Supports two ink cartridges. The color cartridge is installed to the
right while the black cartridge (or the photographic cartridge, sold
separately) is installed to the left.
To replace the ink cartridges, see "Replacement of the ink
cartridges".
12 Front panel USB
interface
Connect the USB cable of the digital camera, a USB memory
(Mass Storage).

Olivetti SIMPLE_WAY Specifications

General

Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	18 ppm
Digital sender	No
Number of print cartridges	6
Input color depth	24 bit
PC free copying	Yes
Maximum copy resolution	1200 x 1200 DPI
Copy speed (black, normal quality, A4)	20 cpm
Copy speed (color, normal quality, A4)	18 cpm
Display	LCD
Display diagonal	2.4 \
Market positioning	Home & office
Maximum print size	100 x 150 mm
Paper tray media types	Envelopes, Iron-On Transfers, Labels, Photo paper
ISO A-series sizes (A0...A9)	A4
Compatibility	IN502, IN501, IN504, IN503, IN506, IN505
Dimensions (WxDxH)	332 x 433 x 186 mm
All-in-one functions	Copy, Scan
Color all-in-one functions	copy, print
Compatible operating systems	Microsoft Windows 98 SE, ME, 2000, XP MAC OSX 10.2
USB 2.0 ports quantity	1
