2 Nomenclature
2.1 Main unit/insertion tube nomenclature
* The operation of the button changes when it is long-pressed. In this manual, the term "short-press" is
used to indicate pressing a button for a short duration, while "long-press" means holding down a
button for at least one second.
No. Name No. Name
1 USB terminal 13
POWER button ( )
2 HDMI Mini terminal 14 AC adapter connector
3 Terminal cover 15 AC adapter connector cover
4 Hand strap (left and right) 16 Insertion tube holder
5 LCD monitor 17 Angulation section
6 Joystick 18 Tip protection hood
7 Battery door lock 19 Insertion tube
8 Battery door 20 Strap holder
9 Tripod mounting hole 21 FRZ/REC button*
10 SD card slot 22 Main unit
11 SD card cover 23 Bend stopper
12 Power indicator
10
1
14
13
12
11
2
3
4
5
6
7
8
9
15
16
17
18
19
20
21
22
23
