2.2 Front panel
23
CLV-190 INSTRUCTION MANUAL
Ch.2
• When the light source is turned ON with no endoscopes connected to the light
source, the airflow indicator "STBY"may blink.
• When the light source is turned ON with no endoscopes connected to the light
source, the lamp indicator "STBY" may blink.
No. Nomenclature Description
15 Airflow indicators These indicators display whether the air-feeding function is activated (“ON”) or not
(“STBY”).
→ Section 5.9, “Air/water feeding”
16 Airflow regulator
indicators
These indicators display the current airflow pressure level setting (Low, Medium, or
High).
→ Section 5.9, “Air/water feeding”
17 Observation mode
indicators
These indicators display whether NBI observation mode is activated (ON) or in normal
white light observation mode (STBY).
→ Section 5.6, “Optical-digital observation”
18 Observation mode
selection indicators
These indicators display which optical-digital observation mode is activated.
→ Section 5.6, “Optical-digital observation”
19 Available
observation mode
indicators
These indicators display the optical-digital observation mode available with the
connected endoscope.
→ Section 5.6, “Optical-digital observation”
20 Lamp indicators These indicators display whether the examination lamp (xenon lamp) lights up (“ON”) or
not (“STBY”).
→ Section 5.3, “Turning the light source ON and igniting the examination lamp”
→ Section 5.10, “Extinguishing the examination lamp”
21 Transillumination
indicator
This indicator lights up when the transillumination function is activated.
→ Section 5.7, “Transillumination function”
22 High intensity mode
indicator
This indicator lights up when the high intensity mode is selected.
→ Section 5.8, “High intensity mode”
23 Brightness indicator These indicators display the current brightness.
→ Section 5.5, “Brightness adjustment”
24 Emergency lamp
indicator
This indicator lights up when the emergency lamp (halogen) is in use and blinks when
the emergency lamp (halogen) is broken, disconnected, or not mounted.
→ Section 4.5, “Inspection of the power supply”
→ Section 4.7, “Inspection of the examination light”
25 Lamp usage
indicator
This indicator displays the total working hours of the examination (xenon) lamp.
→ Section 4.6, “Checking the lamp usage indicator”
26 Brightness mode
indicators
These indicators display the brightness adjustment setting (“AUTO” or “MANU”).
→ Section 5.4, “Setting the brightness mode”
