78
5.9 Air/water feeding
CLV-190 INSTRUCTION MANUAL
Ch.5
Over-insufflating the lumen may cause patient pain, injury, bleeding, gas embolism,
and/or perforation.
5.9 Air/water feeding
1 Confirm that the airflow indicator “ON” lights up.
If not, press the airflow button. The airflow
indicator “ON” lights up to indicate that air is
being fed to the endoscope.
Figure 5.9
2 Press the airflow regulator button to set the
airflow regulator according to the examination
technique and/or patient condition. Each press
of the button changes the airflow regulator
indicators between L (Low), M (Medium), and H
(High).
Figure 5.10
3 Feed water or air as described in the endoscope’s instruction manual.
Airflow indicators
Airflow button
Airflow regulator button
Airflow regulator indicators
