Olympus E-M5 Mark III User Manual

85 EN
Shooting
2
Making fi ne adjustments to white balance (WB Compensation)
Choose white balance compensation values to fi ne-tune auto white balance, preset
white balance, and one-touch white balance.
1
Press the Q button to display the LV super control panel.
2
Use FGHI to select [WB].
3
Use the front dial to select an option.
4
Use FGHI to select the white balance
compensation.
5
Change the white balance compensation value
using the front dial.
• Pressing Q displays hue adjustment options.
White balance compensation
1023
1:02:03
sRGB
Natural
S - AF
S
Normal
WB
Auto
ISO
Auto
± 0
A ± 0
± 0.0
±
0 ± 0
± 0
G ± 0
P
250 F5.6
Auto x
S-IS AUTO
30
p
30
p
4K
M-IS
F
For compensation on the A axis (Red-Blue)
Move the bar in the + direction to emphasize red tones and in the – direction to
emphasize blue tones.
For compensation on the G axis (Green-Magenta)
Move the bar in the + direction to emphasize green tones and in the – direction to
emphasize magenta tones.
• White balance compensation can be applied to all white balance modes simultaneously.
g [All x] (P. 171)
%
• To preview the effects of changes to white balance, press the R (movie) button. A sample
image captured at the selected white balance will be displayed.

Olympus E-M5 Mark III Specifications

General

Flip-out screen	-
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	Yes
Display resolution (numeric)	1037000 pixels
Magnification	1.37 x
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
PictBridge	No
USB version	2.0
HDMI connector type	Micro
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Flash modes	Auto, Fill-in, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	256000
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLS‑50
Battery life (CIPA standard)	310 shots
Product color	Black
Image editing	Crop, Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Auto, Manual, Program, Scene
Self-timer delay	2, 12 s
Digital zoom	- x
Focal length range	14 - 150 mm
Maximum aperture number	4
Minimum aperture number	5.6
Bluetooth version	4.2
Megapixel	20.4 MP
Camera type	MILC
Sensor type	Live MOS
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888

Weight and Dimensions

Depth	49.7 mm
Width	125.3 mm
Height	85.2 mm
Weight	366 g
Weight (including battery)	414 g
