Lambda series
（acquiring by multiple channels）
Setting the wavelength
⑨ Set them by dragging the mouse on the
profile display area or set the value of
wavelength directly to [CH1].（★）
Adjusting the live image
⑩ Press the button to start
scanning.
⑪ In ⑪ in left figure, enter the value of
wavelength directly, to find the most
efficient (brightest) range. Entering
the value in the left box, changes the
value in the right box based on
Bandwidth automatically.
⑫ Adjust the laser intensity,
sensitivity(HV),Gain and Offset. Press
the and adjust not to saturate
the image intensity.
Acquiring the image
⑬ Select [Normal] tab in [Acquire] Tool
Window. Press the button to
display the dialog box, and select the
folder to save the images.
*The acquire images are saved
automatically. Serial number is added
at the end of file name like
“***_0001” and “***_0002”.
⑭ Press button to start
acquiring the image.
（★）
drag the gray
cube to set the
wavelength range.
linking
You can enter the value directly
⑨
⑪
⑫
⑫
⑪
⑫
⑬
⑭
29
*You cannot select the laser which includes
±5nm of the excitation wavelength in the
photometry range of each channel.
