XY Image Acquisition(２)
Setting the scanner
⑩ On [LSM Imaging] Tool Window, select the
scan method in [Type] and [Mode].
※See 23 pages for details.
⑪ Set scanning speed.
⑫ Specify “Image Size” to set the scan area.
⑬ Set the zoom, rotation and clip scan if
needed.
Starting Acquisition
⑭Select [Normal] tab in [Acquire] Tool Window.
Press the button to open the dialog
box, and select the folder to save the images.
*The acquired images are saved automatically.
Serial number is added at the end of file name
like “***_0001” and “***_0002”.
⑮Press button to start acquiring the
image.
5
DIC observation
1. Insert the DIC slider to microscope.
2. Register the TD channel.
3. Set the laser to be used for observation.
4. Adjust the sensitivity(HV).
5. Adjust the contrast by rotating the knob of
the DIC slider.
(See page 3 ⑤ in left side. )
Attention
Check [LSM] in [Series] Tool Window whether it
is selected “OFF” [Z] and [Time] .
⑩
⑪
⑫
⑬
⑮
⑭
4.
3.
To Next Page
