Specifications
100
i--SPEED LT, i--SPEED 2
Chapter 11 Specifications
11.1 i- SPEED LT, i- SPEED 2 Camera
` Camera physical
Dimensions
Size W 106mm x H 98mm x L 264mm nominal
Weight 2kg nominal
Mechanical connections
Tripod mounting
1x standard tripod mount (¼” Whitworth thread)
Lens mounting Standard C--mount
Back focus Nominal position 17mm. C--mount can be screwed
in 1mm & out 3mm.
Rotary control locks the C--mount in position
Accessory mounting
4x ¼” Whitworth thread fixing holes on the base
` Electrical connections
Power input Lemo EGG.OB.304.CLV
Pinout 1 Ground 3 +12V
2 +12V 4 Ground
Input voltage
12VDC ±10%
Power consumption Camera: 28W max
System: 36W max
Fuse
Type 20 x 5mm cartridge (coin slot screw access)
Rating T3.15AH 250V
Controller Connector
Standard LVDS connector, 26 way MDR
