Olympus i-SPEED 2 User Manual

Specifications
102
i--SPEED LT, i--SPEED 2
Ethernet RJ45
Pinout 1 TXD1+ 5 NC
2 TXD1-- 6 RXD2--
3 RXD2+ 7 NC
4 NC 8 NC
Ethernet signal 10 / 100 Base--T, auto switching
Link (in RJ45) Link status is indicated by two bi--colour red--green
LED’s:
Top red: 100Mb connection, half--duplex link
Top green: 100Mb connection, full--duplex link
Bottom red: 10Mb connection, half--duplex link
Bottom green: 10Mb connection, full--duplex link
Activity (in RJ45) Indicated by flashing of the appropriate LED in the
appropriate colour (see above)
SVGA 15 way high density D sub female, PC standard
Pinout 1 Red video 6 Red ground
2 Green video 7 Green ground
3 Blue video 8 Blue ground
13 Horizontal sync 10 Sync ground
14 Vertical sync * Other pins no
connection
SVGA video output SVGA (800 x 600) 60Hz
Composite
video out
BNC
Standard NTSC / PAL switchable
Level 1Vp--p
Impedance 75 Ohms
Compact flash
Standard Type I and II
Vpp Level 0V, 3V3, auto select
Vcc Level 3V3
Connection Hot swappable
